Name: [AC01] Type 2 to Type E / F (1 x 16A)
SKU: AC01
Availability: InStock

[AC01] Type 2 to Type E / F (1 x 16A)

€ 150,00 – € 158,00 ex.VAT

This connector can only be used on charging stations with Type 2 socket, to provide power to devices with domestic SCHUKO plug (like E scooters, E motor bikes, E quadricycles). Our new design of AC01 has a temperature sensor that prevents potentially weak/damaged domestic plug to overheat, so it is safe to connect loads with up to 3,7 kW/16A power.

User manual – ENG

Bedienungsanleitung – DE

Användarmanual – SWE

Manuel d’utilisation – FR

Uputstva za upotrebu – HR

Description

Main features:

Connector Type 2 (Mennekes) – to domestic socket 16A single phase, electronics included.

EU DECLARATION OF CONFORMITY
SIQ TEST REPORT – PREVIEW

Technical Specifications:

Maximum continuous current [A]: 16
Ingress protection [IP] rating: 44 (moisture proof)
Operating Ambient Air Temperature Range [C°]: from -40 to +50
UV resistance: YES
Domestic socket over-temperature protection: YES
Dimensions [Φmax / Length]: 58 mm / 184 mm
Weight: 215g
Warranty: 3 years

Green production

All our products are produced in a carbon neutral way by using “Sustainable energy cycle” method. Production plant where we make charging cables and portable charging stations is the first fully sustainable production facility for EV charging cables. All energy, needed for the heating and cooling of the building, production process and for transportation of goods and employees (except deliveries of heavy materials by trucks), is produced by 2 photovoltaic power plants and stored in 4 storage batteries. Almost all of the raw materials we use (cables, plugs) are produced in EU, to shorten supply routes and support local economy. Buying our products helps developing sustainable economy.
