[CC06] Type 2 to Type 2 (32A, 3-phase)

Description

Main features:

• Designed for 3-phase EV charging with currents up to 3 x 32A (22 kW)
• High-quality cable designed for electric vehicles (made in Germany)
• 3-YEAR WARRANTY

Technical specifications:

• Plug Type (EV Side): Type 2 (IEC 62196) Female Plug
• Plug Type (Charging Station Side): Type 2 (IEC 62196) Male Plug
• Max. Charging Current: 3x32A (3-phase) or 1x32A (1-phase)
• Max. Charging Power: 22 kW (3-phase) or 7.4 kW (1-phase)
• Rated Voltage: 400V (3-phase)
• Cable length: 6 m
• UV, oil and flame resistant cable insulation
• Operating Ambient Air Temperature Range: -30 °C to +50 °C
• IP Rating: IP44
• Cable color: orange
• Weight: 2.90 kg
• 100% compatible with all electric vehicles equipped with European Type 2 charging socket.
