PC05X+ 3x16A / 3-phase

Description

Main features:

• World’s smallest and lightest Type 2 socket/outlet SMART portable EV charging station
• 100% in-house developed miniature SMART vehicle communication module inside (Micro EVSE 4+)
• Adjustable charging current (from 6A to 16A)
• Designed for 3-phase and 1-phase Mode 2 EV charging with currents up to 3x16A
• WiFi access point with preloaded METRON Charge Control application (user can set charging power, solar surplus charging, see real time charging power & energy, house power, solar power, connect to WiFi network,…)
• OTA (over-the-air) updates (via WiFi) for Charge Control application
• Ready for wireless DYNAMIC LOAD MANAGEMENT (DLM) via additional METRON Wireless Dynamic EV Charging Unit (model 3FD-3) for protecting main house fuses, adding solar power plant power to maximize charging power/speed and “green” solar surplus charging (special Metron proprietary Dynamic Power Control System algorithms inside)
• Silver plated multi-contact Type2 power contacts ensure minimum possible heat dissipation
• Integrated self-resettable over-temperature protection with SOFT-OFF capability
• Built-in RCD (30mA AC + 6mA DC) with automatic self-test for maximum user safety
• 100% all weather proof (IP67)

Optional accessory:

• Type 2 plug lock with key –  https://eauto.si/metron-shop/product/lock-and-key/

SPECIAL feature:

In case of using the SMART PORTABLE CHARGING STATION(s) PC03X+ / PC04X+ / PC05X+ on 2 or more different places (e.g. you have 2 houses) it is possible to install the 3FD-3 WIRELESS DYNAMIC EV CHARGING UNITs on 2 or more different locations (e.g. 2 houses) with different main fuses and then just move/use the same SMART PORTABLE CHARGING STATION on those different locations and have everywhere safe wireless FUSE protection DYNAMIC charging. The SMART PORTABLE CHARGING STATION connects AUTOMATICALLY to the 3FD-3 unit at every location.

EU DECLARATION OF CONFORMITY

SIQ TEST REPORT – PREVIEW
Technical Specifications:

• Charging socket Type (to EV): Type 2 (IEC 62196) Female socket
• Wall Plug Type (grid side): CEE 16A (3-phase/3P N E) or any other on request
• Max. Charging Current: 3x16A (3-phase) or 1x16A (single phase – using appropriate adaptor)
• Charging current can be adjusted by front button: 6A, 8A, 10A, 13A or 16A (no smart phone needed)
• Charging current can be adjusted by slider in Charge Control app. by 1A from 6A to 16A (smart phone needed)
• Max. Charging Power (single/three phase): 3,7 kW/11 kW
• Rated Voltage (single/three phase): 230/400V
• Operating voltage range (single/three phase): from 90V/155V to 270V/470V (50/60Hz)
• Idle power consumption: 4 W
• Micro EVSE 4+ in-house developed FULL feature vehicle communication module inside
• User info via 2 blue LED lights (basic) and Charge Control app. (advanced)
• Supports OTA (over-the-air) uploads of future versions of Charge Control application firmware
• Supported WiFi standards: IEEE 802.11b/g/n
• WiFi speed: up to 150 Mbit/s
• WiFi security: WPA2
• WiFi signal range: up to 20 m
• Allows connecting the portable charging station to local WiFi network and also set the charging station internet access in the WiFi router (advanced users)
• Detects/indicates ALL normal charging states (via blue status LED)
• Detects/indicates ALL faults (via blue status LED)
• Auto recovers from any fault except ground fault
• Built-in ground fault protection device – RCD (30mA AC + 6mA DC) for maximum user safety
• Built-in automatic RCD self-test
• Built-in power contactor weld detection system
• Wall plug integrated OVER-TEMPERATURE PROTECTION (on request)
• Operating Ambient Air Temperature Range: -30 °C to 50 °C (at full sun exposure)
• Integrated self re-settable over-temperature protection with SOFT-OFF capability
• IP Rating: IP67 (100% all weather proof )
• IK rating: IK10 (impact/shock proof) + drive-over proof
• UV resistant
• Color: black
• Weight: only 1 kg
• Length/Width: 47 cm / 7 cm max.
• IEC 61851 compliant
• CE approved
• Warranty: 2 years

Over-the-air (OTA) software update procedure:

ATTENTION: OTA update is only available with Metron Dynamic Power Control application version v3.20 or higher. To update older versions of 3FD-3 or 3FD-3.1 wireless dynamic modules, you only need to bring or send the unit to Metron, Podnart 33, 4244 Podnart, Slovenia. The update is free of charge.

For the 3FD-3 or 3DF-3.1 Wireless Dynamic Module:

• In the Metron Dynamic Power Control application, go to the “Settings” menu
• press the Start OTA update button in the OTA update window
• enter “metron” for username and “20dgfh11” for password
• The latest firmware version is available here: https://eauto.si/OTA/3FD-3_WiFi_Dynamic_Power_Control.bin

For X+ smart portable chargers:

• In the Metron Charge Control app, go to the “Settings” menu
• press the Start OTA update button in the OTA update window
• enter “metron” for the username and “20dgfh11” for the password
• The latest firmware version is available here: https://eauto.si/OTA/Micro_EVSE_4_WiFi_Charge_Control_X.bin

Green production

All our products are produced in a carbon neutral way by using “Sustainable energy cycle” method. Production plant where we make charging cables and portable charging stations is the first fully sustainable production facility for EV charging cables. All energy, needed for the heating and cooling of the building, production process and for transportation of goods and employees (except deliveries of heavy materials by trucks), is produced by 2 photovoltaic power plants and stored in 4 storage batteries. Almost all of the raw materials we use (cables, plugs) are produced in EU, to shorten supply routes and support local economy. Buying our products helps developing sustainable economy.

Compatibility:

100% compatible with all electric vehicles.

WHAT IS RCD AND HOW DOES IT WORK?

RCD is an acronym for Residual Current Device – sometimes it can be called also Earth Leakage Circuit Breaker or Safety Switch. Its purpose is to prevent you from
getting a fatal electric shock if you touch live part, such as a bare copper wire under high voltage. RCDs offer a level of personal protection that ordinary
fuses/circuit-breakers cannot provide. RCD constantly monitors the electric current flowing through one or more circuits which it protects. If it detects electricity
flowing down an unintended path, such as through a person who has touched a live part, the RCD will switch the circuit off very quickly, significantly reducing the risk
of death or serious injury. Every portable charging station has integrated Type A 30mA AC + 6mA DC RCD what ensures maximum possible level of personal
protection as it protects users from AC, pulsating DC and pure DC leakage currents.

RENAULT ZOE NOTES:

1. This portable EV charging station is designed to work also with Renault ZOE (all motor versions are supported) what means Renault ZOE won’t damage this portable charger – won’t weld internal contactors!
2. Before charging starts Renault ZOE’s on-board charger system checks if the wall socket from which you want to charge the car is correctly connected to a GOOD electrical grid otherwise ZOE won’t start charging. The wall socket/grid must have the following characteristics:

• Phase sequence in wall socket must be in clockwise rotation (L1-L2-L3). If the wall socket phase sequence is L3-L2-L1 (counterclockwise) some Zoe versions won’t charge! To check phases and phase sequence you can use our PHASE TESTER device.
• Electrical grid behind wall socket must have low impedance (cables with conductor cross sections must have at least 2.5mm2)
• Earthing/grounding: earth resistance should be less than 100 Ohm
• The voltage difference between neutral and earth should be very low (if this is a problem it can be solved by an experienced electrician in the way neutral and earth are connected together in a wall socket if there is no RCD protection in the building or before RDC protection device if it exists)
• Wall socket RCD (Ground fault protection) device shall be Type A (30mA) or Type A with added 6mA DC RCD or Type B or NONE as this portable charging station features integrated RDC (30mA AC + 6mA DC) for maximum user safety. RCD Type AC (30mA) is not appropriate, because it can be activated by Renault ZOE charging system!
• When charging at single phase (using CEE to schuko adapter) it is important that phase and neutral are correctly positioned. If it doesn’t work turn schuko domestic plug by 180 deg. and it will (most likely) work.
